NCE20PK0402U Datasheet, Mosfet, NCE Power Semiconductor

NCE20PK0402U Features

• Mosfet MOSFET
• VDS = -20V,ID = -4.3A RDS(ON) < 80mΩ @ VGS=-4.5V RDS(ON) < 100mΩ @ VGS=-2.5V RDS(ON) < 160mΩ @ VGS=-1.8V Schottky Diode
• VKA(V) = 20V, IF = 2A, VF<0.45V@0.5A A

PDF File Details

Part number:

NCE20PK0402U

Manufacturer:

NCE Power Semiconductor

File Size:

294.49kb

Download:

📄 Datasheet

Description:

P-channel enhancement mode power mosfet. The NCE20PK0402U uses advanced trench technology to provide excellent RDS(ON), low gate charge. A Schottky diode is provided to facil

NCE20PK0402U Application

• Applications General Features MOSFET
• VDS = -20V,ID = -4.3A RDS(ON) < 80mΩ @ VGS=-4.5V RDS(ON) < 100mΩ @ VGS=-2.5V RDS(ON) < 160mΩ @ VGS=
