NCE40H20AD Datasheet, Mosfet, NCE Power Semiconductor

NCE40H20AD Features

• Mosfet
• VDS = 40V,ID =200A RDS(ON) < 2.6mΩ @ VGS=10V (Typ:2.0mΩ)
• Special process technology for high ESD capability
• High density cell design for ultra low Rdson

PDF File Details

Part number:

NCE40H20AD

Manufacturer:

NCE Power Semiconductor

File Size:

304.06kb

Download:

📄 Datasheet

Description:

N-channel enhancement mode power mosfet. The NCE40H20AD uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide

NCE40H20AD Application

• Applications General Features
• VDS = 40V,ID =200A RDS(ON) < 2.6mΩ @ VGS=10V (Typ:2.0mΩ)
• Special process technology for high E
