Part number: BFG10
Manufacturer: NXP (https://www.nxp.com/)
File Size: 74.77KB
Download: 📄 Datasheet
Description: NPN 2 GHz RF power transistor
* High power gain
* High efficiency
* Small size discrete power amplifier
* 1.9 GHz operating area
* Gold metallization ensures excellent reliability..
* Common emitter class-AB operation in hand-held radio equipment at 1.9 GHz. DESCRIPTION NPN silicon planar epitaxia.
NPN silicon planar epitaxial transistor encapsulated in plastic, 4-pin dual-emitter SOT143 package. PINNING PIN DESCRIPTION
BFG10; BFG10/X
BFG10 (see Fig.1) 1 2 3 4 collector base emitter emitter
handbook, 2 columns 4
3
1 Top view
2
MSB014
BFG.
