Part number: BFG11W
Manufacturer: NXP (https://www.nxp.com/)
File Size: 98.04KB
Download: 📄 Datasheet
Description: NPN 2 GHz power transistor
* High power gain
* High efficiency
* Small size discrete power amplifier
* 1.9 GHz operating area
* Gold metallization ensures excellent reliability .
* Common emitter class-AB operation in handheld radio equipment at 1.9 GHz such as DECT, PHS.
* Driver for DCS 1.
NPN silicon planar epitaxial transistor encapsulated in a plastic 4-pin dual-emitter SOT343 package.
Marking code: S4 1 Top view 2
handbook, halfpage
BFG11W/X
PINNING - SOT343 PIN 1 2 3 4 collector emitter base emitter DESCRIPTION
4
3
MBK523
Fig.
