Part number: BFG10X
Manufacturer: NXP (https://www.nxp.com/)
File Size: 58.41KB
Download: 📄 Datasheet
Description: UHF power transistor
* High efficiency
* Small size discrete power amplifier
* 900 MHz and 1.9 GHz operating areas
* Gold metallization ensures excellent reliability. APPLICAT.
* Common emitter class-AB operation in hand-held radio equipment up to 1.9 GHz. DESCRIPTION NPN silicon planar epita.
NPN silicon planar epitaxial transistor encapsulated in a plastic, 4-pin dual-emitter SOT343 package. PINNING PIN 1 2 3 4 DESCRIPTION collector emitter base emitter
Marking code: T5. 1
BFG10W/X
fpage
4
3
2
MBK523
Top view
Fig.1 SOT343. QUICK R.
Image gallery
TAGS
📁 Related Datasheet
BFG10 - NPN 2 GHz RF power transistor
(NXP)
DISCRETE SEMICONDUCTORS
