Part number: BFG10W
Manufacturer: NXP (https://www.nxp.com/)
File Size: 55.89KB
Download: 📄 Datasheet
Description: UHF power transistor
The BFG10W is a silicon NPN wideband microwave transistor manufactured by NXP Semiconductors. It is commonly used in high-frequency applications such as wireless communication systems, radar systems, and other RF amplification circuits. The transistor features high power gain and excellent linearity, making it suitable for applications that require low noise and high power output..
NPN silicon planar epitaxial transistor encapsulated in a plastic, 4-pin dual-emitter SOT343 package.
PINNING
PIN DESCRIPTION 1 collector 2 emitter 3 base 4 emitter
fpage
4
3
1 Top view
2
MBK523
Marking code: T5.
Fig.1 SOT343.
QUICK REFERENCE .
* High efficiency
* Small size discrete power amplifier
* 900 MHz and 1.9 GHz operating
areas
* Gold metallization ensures
excellent reliability.
APPLICAT.
* Common emitter class-AB operation in hand-held radio equipment up to 1.9 GHz.
DESCRIPTION NPN silicon planar epit.
Image gallery
