NCP51105 - Low-Side Gate Driver

Product Overview

ON Semiconductor

Datasheet Details

Part number	NCP51105
Manufacturer	ON Semiconductor
File Size	351.92 KB
Description	Low-Side Gate Driver
Datasheet	NCP51105 Datasheet
Additional preview pages of the NCP51105 datasheet.

Product details

Description

Pin Name OCP ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ GND ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ OUT ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ VDD ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ EN ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ IN Pin No.1 2 3 4 5 6 Description Current sense input with negative voltage Ground that all signals are referenced Sourcing and sinking current output of driver Bias supply input Enable I/O for three

Features

Wide Operating Voltage Range: up to 25 V.
2.6 A Peak Sink/Source.
Shorter than 50 ns Propagation Delay Time.
Over Current Protection with Negative Voltage Sensing.
Input Logic Compatible with Wide Voltage Range for TTL & CMOS.
Programmable Fault Clear Time.
Under Voltage Lockout for MOSFET and IGBT.
This Device is Pb.
Free, Halide Free and is RoHS Compliant Typical.
