HIP0082 Datasheet, Driver, Renesas

HIP0082 Features

• Driver
• Low Side Power MOSFET Output Drivers - Output Voltage Clamp (Typ) . . . . . . . . . . . . . . . . . 80V - Maximum Output Current . . . . . . . . . . . . . . . . 5A/2A - Outpu

PDF File Details

Part number:

HIP0082

Manufacturer:

Renesas ↗

File Size:

1.03MB

Download:

📄 Datasheet

Description:

Quad power driver. The HIP0082 and HIP0084 Quad Power Drivers contain four individually protected NDMOS transistor switches to drive inductive and resis

HIP0082 Application

• Applications
• Drivers For - Solenoids - Relays - Power Output - Lamps - Injectors - Steppers - Motors - Displays
• System Use -
