STGIPQ3H60T-HL - 3-phase IGBT

STMicroelectronics

STGIPQ3H60T-HL Datasheet Preview — Preview of STGIPQ3H60T-HL PDF

Datasheet Details

Part number	STGIPQ3H60T-HL
Manufacturer	STMicroelectronics ↗
File Size	1.36 MB
Description	3-phase IGBT
Datasheet	STGIPQ3H60T-HL-STMicroelectronics.pdf

STGIPQ3H60T-HL Product details

Description

This second series of SLLIMM (small low-loss intelligent molded module) nano provides a compact, high-performance AC motor drive in a simple, rugged design.

Features

IPM 3 A, 600 V, 3-phase IGBT inverter bridge including 3 control ICs for gate driving and freewheeling diodes.
3.3 V, 5 V, 15 V TTL/CMOS input comparators with hysteresis and pull-down/ pull-up resistors.
Internal bootstrap diode.
Optimized for low electromagnetic interference.
Undervoltage lockout.
VCE(SAT) negative temperature coefficient.
Shutdown function.
Interlocking function.
Op-amp for advanced current sens.
