STH270N4F3-6 Datasheet (STMicroelectronics)

STH270N4F3-6, N-Channel Power MOSFET

This STripFET™ III Power MOSFET technology is among the latest improvements, which have been especially tailored to minimize on-state resistance providing superior switching performance.

www.DataSheet4U.com Table 1.

Device summary Order code Marking 270N4F3 Package H 2PAK Packaging Tape and reel

STH270N4F3-6 Features

* Type STH270N4F3-6 VDSS 40 V RDS(on) < 1.7 mΩ ID (1) 180 A TAB 1. Current limited by package

* Conduction losses reduced Low profile, very low parasitic inductance, high current package 1 H2PAK-6l 7 Applications

* Switching application

* Automotive Figure 1. Internal schema
