STPS80170C-T

Power Schottky Rectifier

STPS80170C-T Features

* AEC-Q101 qualified

* PPAP capable

* Negligible switching losses

* High junction temperature capability

* Good trade off between leakage current and forward voltage drop

* Low leakage current

* Avalanche capability

* Low thermal resist

STPS80170C-T General Description

Dual center tap Schottky rectifier designed for high frequency switched mode power supplies such as on board DC/DC converters for automotive applications. DS13161 - Rev 1 - November 2019 For further information contact your local STMicroelectronics sales office. www.st.com STPS80170C-Y Characteri.

STPS80170C-T Datasheet (214.25 KB)

Preview of STPS80170C-T PDF

Datasheet Details

Part number:

STPS80170C-T

Manufacturer:

STMicroelectronics ↗

File Size:

214.25 KB

Description:

Power schottky rectifier.
STPS80170C-Y Datasheet Automotive 170 V, 80 A power Schottky rectifier A1 K A2 TO-247 LL A2 K A1 Product status STPS80170C-Y Product summary IF(.
