U74CBT3253 - DUAL 1-OF-4 FET MULTIPLEXER/EMULTIPLEXER

U74CBT3253 Description

UNISONIC TECHNOLOGIES CO., LTD U74CBT3253 DUAL 1-OF-4 FET MULTIPLEXER/EMULTIPLEXER * .
The U74CBT3253 is a dual 1-of-4 high-speed TTL-compatible FET multiplexer/demultiplexer.

U74CBT3253 Features

* VCC Operating Range From 4V to 5.5V
* Bidirectional Data Flow, With minimal Propagation Delay
* Low ON-State Resistance (RON) Characteristics (RON =5Ω Typ. )
* Low Power Consumption ICC =3μA (Max. )
* ORDERING INFORMATION Ordering Number Lead Free Halogen Free U74CBT3253L-S1

📥 Download Datasheet

Preview of U74CBT3253 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
U74CBT3253
Manufacturer
Unisonic Technologies
File Size
190.93 KB
Datasheet
U74CBT3253-UnisonicTechnologies.pdf
Description
DUAL 1-OF-4 FET MULTIPLEXER/EMULTIPLEXER
