U74HC04 Datasheet, inverters equivalent, Unisonic Technologies

U74HC04 Features

• Inverters
• Wide Operating Voltage Range of 2V to 6V
• Outputs Can Drive Up To 10 LSTTL Loads
• Low Power Consumption, 2μA Max ICC
• Typical tpd=8ns
• ±4mA

PDF File Details

Part number:

U74HC04

Manufacturer:

Unisonic Technologies

File Size:

224.12kb

Download:

📄 Datasheet

Description:

Hex inverters. The U74HC04 devices contain six independent inverters. They perform the Boolean function Y  A in positive logic.
