IHLP2525CZER1R0M01 Datasheet, Inductor, Vishay Siliconix

IHLP2525CZER1R0M01 Features

• Inductor
• Lowest height (3.0mm) in this package footprint.
• Shielded construction.
• Frequency range up to 5.0MHz.
• Lowest DCR/µH, in this package size. Manuf

PDF File Details

Part number:

IHLP2525CZER1R0M01

Manufacturer:

Vishay ↗ Siliconix

File Size:

466.17kb

Download:

📄 Datasheet

Description:

High current inductor. IHLP-2525CZ-01 MODEL 1.0µH INDUCTANCE VALUE ± 20% INDUCTANCE TOLERANCE ER PACKAGE CODE e3 JDEC LEAD FREE STANDARD GLOBAL PART NUMBER

IHLP2525CZER1R0M01 Application

• Applications
• PDA/Notebook/Desktop/Server applications.
• High current POL converters.
• Low profile, high current power su
