PE2301 Datasheet, Mosfet, semi one

PE2301 Features

• Mosfet
• VDS = -20V,ID = -3A RDS(ON) = 110mΩ @ VGS=-2.5V RDS(ON) = 85 m Ω @ VGS=-4.5V D G S Schematic diagram
• High Power and current handing capability
• Lead free

PDF File Details

Part number:

PE2301

Manufacturer:

semi one

File Size:

196.61kb

Download:

📄 Datasheet

Description:

P-channel enhancement mode power mosfet. The PE2301 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2

PE2301 Application

• Applications GENERAL FEATURES
• VDS = -20V,ID = -3A RDS(ON) = 110mΩ @ VGS=-2.5V RDS(ON) = 85 m Ω @ VGS=-4.5V D G S Schematic diagram
