PE2306A Datasheet, Mosfet, ChipSourceTek

PE2306A Features

• Mosfet
• VDS 20V,ID =1.6A Schematic diagram RDS(ON) <85mΩ @ VGS=4.5V RDS(ON) <110mΩ @ VGS=2.5V
• Surface Mount Package Application
• Load/ power switching cell phon

PDF File Details

Part number:

PE2306A

Manufacturer:

ChipSourceTek

File Size:

786.57kb

Download:

📄 Datasheet

Description:

Enhancement mode power mosfet. D The PE2306A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with low gate voltage.
