PE2023, PE2023-ChipSourceTek - P-Channel Enhancement Mode Power MOSFET

PE2023 Description

PE2023 P-Channel Enhancement Mode Power MOSFET .
The PE2023 uses advanced trench technology to provide excellent RDS(ON) and low gate charge.

PE2023 Features

* VDS = -20V, ID = -3.2A RDS(ON) < 95mΩ @ VGS=-4.5V RDS(ON) < 120mΩ @ VGS=-2.5V Schematic diagram
* High Power and current handing capability
* Lead free product is acquired

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: PE2023, PE2023-ChipSourceTek. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
PE2023, PE2023-ChipSourceTek
Manufacturer
ChipSourceTek
File Size
719.84 KB
Datasheet
PE2023-ChipSourceTek_removed.pdf
Description
P-Channel Enhancement Mode Power MOSFET
Note
This datasheet PDF includes multiple part numbers: PE2023, PE2023-ChipSourceTek.
Please refer to the document for exact specifications by model.
