PE2302A Datasheet, Mosfet, ChipSourceTek

PE2302A Features

• Mosfet
• VDS = 20V, ID =3A RDS(ON) < 45mΩ @VGS=4.5V RDS(ON) < 55mΩ @VGS=2.5V Schematic diagram
• High Power and current handing capability
• Lead free product is acq

PDF File Details

Part number:

PE2302A

Manufacturer:

ChipSourceTek

File Size:

735.85kb

Download:

📄 Datasheet

Description:

N-channel enhancement mode power mosfet. The PE2302A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of app

PE2302A Application

• Applications PE2302A General Features
• VDS = 20V, ID =3A RDS(ON) < 45mΩ @VGS=4.5V RDS(ON) < 55mΩ @VGS=2.5V Schematic diagram
