PE2319, PE2319-ChipSourceTek - P-Channel Enhancement Mode Power MOSFET

PE2319 Description

PE2319 P-Channel Enhancement Mode Power MOSFET .
The PE2319 uses advanced trench technology to provide excellent RDS(ON) and low gate charge.

PE2319 Features

* VDS > -18V, ID = -7A RDS(ON) < 21mΩ @ VGS=-4.5V RDS(ON) < 28mΩ @ VGS=-2.5V Schematic diagram
* High Power and current handing capability
* Lead free product is acquired

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: PE2319, PE2319-ChipSourceTek. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
PE2319, PE2319-ChipSourceTek
Manufacturer
ChipSourceTek
File Size
797.05 KB
Datasheet
PE2319-ChipSourceTek_removed.pdf
Description
P-Channel Enhancement Mode Power MOSFET
Note
This datasheet PDF includes multiple part numbers: PE2319, PE2319-ChipSourceTek.
Please refer to the document for exact specifications by model.
