Part number: ADP2107
Manufacturer: Analog Devices (https://www.analog.com/)
File Size: 0.98MB
Download: 📄 Datasheet
Description: Step-Down DC-to-DC Converter
Extremely high 97% efficiency Ultralow quiescent current: 20 μA 1.2 MHz switching frequency 0.1 μA shutdown supply current Maximum load current
ADP2105: 1 A ADP2106: 1.5 .
Mobile handsets PDAs and palmtop computers Telecommunication/networking equipment Set top boxes Audio/video consumer ele.
The ADP2105/ADP2106/ADP2107 are low quiescent current, synchronous, step-down dc-to-dc converters in a compact 4 mm × 4 mm LFCSP package. At medium to high load currents, these devices use a current mode, constant frequency pulse-width modulation (P.
