PE8124HM1 Datasheet, Mosfet, ChipSourceTek

PE8124HM1 Features

  • Mosfet
  • VDS > 12V, ID = 24A RDS(ON) < 3.9mΩ @ VGS=4.5V RDS(ON) < 4.2mΩ @ VGS=3.8V RDS(ON) < 4.6mΩ @ VGS=3.0V RDS(ON) < 5.4mΩ @ VGS=2.5V Schematic diagram ESD Rating: 4000V HBM

PDF File Details

Part number:

PE8124HM1

Manufacturer:

ChipSourceTek

File Size:

755.82kb

Download:

📄 Datasheet

Description:

N-channel enhancement mode power mosfet. The PE8124HM1 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of a

Datasheet Preview: PE8124HM1 📥 Download PDF (755.82kb)
Page 2 of PE8124HM1 Page 3 of PE8124HM1

PE8124HM1 Application

  • Applications It is ESD protected. General Features
  • VDS > 12V, ID = 24A RDS(ON) < 3.9mΩ @ VGS=4.5V RDS(ON) < 4.2mΩ @ VGS=3.8V RDS(ON) < 4
