High P C and h FE, excellent
hFE linearity, complementary pair with 9015M(3CG9015M). /Absolute maximum ratings(Ta=25℃)
Symbol Rating Unit
VCBO VCEO VEBO IC PC Tj Tstg
50 45 5.0 100 400 150 -55～150
V V V mA mW ℃ ℃
/Electrical characteristics(Ta=25℃)
Symbol
Test condition
Rating
Max Unit
Min
Typ
VCBO VCEO VEBO ICBO IEBO hFE VCE(sat) VBE(sat) VBE fT Cob NF
IC=0.1mA IC=1.0mA IE=0.1mA VCB=50V VEB=5.0V VCE=5.0V IC=100mA IC=100mA VCE=5.0V VCE=5.0V VCB=10V VCE=5.0V Rg=2.0KΩ
IE=0.
