ISL9V5045S3ST_F085 Datasheet, igbt equivalent, Fairchild Semiconductor

ISL9V5045S3ST_F085 Features

• Igbt
• SCIS Energy = 500mJ at TJ = 25oC
• Logic Level Gate Drive
• Qualified to AEC Q101
• RoHS Compliant Applications
• Automotive Ignition Coil Driv

PDF File Details

Part number:

ISL9V5045S3ST_F085

Manufacturer:

Fairchild Semiconductor

File Size:

232.28kb

Download:

📄 Datasheet

Description:

Ecospark n-channel ignition igbt. The ISL9V5045S3ST_F085 is next generation ignition IGBT that offer outstanding SCIS capability in the industry standard D2-Pak (TO-26

ISL9V5045S3ST_F085 Application

• Applications
• Automotive Ignition Coil Driver Circuits
• Coil - On Plug Applications General Description The ISL9V5045S3ST_F085 is
