CS13N50A8D Datasheet, Mosfet, Huajing Microelectronics

CS13N50A8D Features

• Mosfet l Fast Switching l ESD Improved Capability l Low Gate Charge (Typical Data:40nC) l Low Reverse transfer capacitances(Typical:17pF) l 100% Single Pulse avalanche energy Test Application

PDF File Details

Part number:

CS13N50A8D

Manufacturer:

Huajing Microelectronics

File Size:

488.79kb

Download:

📄 Datasheet

Description:

Silicon n-channel power mosfet. CS13N50 A8D, the silicon N-channel Enhanced VDMOSFETs, is obtained by the self-aligned planar Technology which reduce the conduct

CS13N50A8D Application

• Applications Power switch circuit of adaptor and charger. Absolute（Tc= 25℃ unless otherwise specified）： Symbol Parameter VDSS ID IDMa1 VGS EAS a
