2SD2579 - NPN Transistor

2SD2579 Description

isc Silicon NPN Power Transistor .
High Breakdown Voltage- : VCBO= 1500V (Min). High Switching Speed. High Reliability. Minimum Lot-to-Lot variations for robust device.

2SD2579 Applications

* Color TV horizontal deflection output applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage 1500 V VCEO Collector-Emitter Voltage 800 V VEBO Emitter-Base Voltage 6 V IC Collector Current- Continuous 8 A ICP Collector Current

📥 Download Datasheet

Preview of 2SD2579 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SD2579
Manufacturer
INCHANGE
File Size
212.43 KB
Datasheet
2SD2579-INCHANGE.pdf
Description
NPN Transistor
