IXTH270N04T4 Datasheet - INCHANGE

IXTH270N04T4, N-Channel MOSFET

isc N-Channel MOSFET Transistor *.

datasheet Preview Page 1 from Datasheet4u.com

IXTH270N04T4-INCHANGE.pdf

IXTH270N04T4 Datasheet Preview — Preview of IXTH270N04T4 PDF

Datasheet Details

Part number:

IXTH270N04T4

Manufacturer:

INCHANGE

File Size:

334.68 KB

Description:

N-Channel MOSFET

Features

* Static drain-source on-resistance: RDS(on) ≤ 4.7mΩ@VGS=10V
* Fully characterized avalanche voltage and current
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

Applications

* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBO L PARAMETER VALUE VDSS Drain-Source Voltage 100 UNIT V VGS Gate-Source Voltage ±20 V ID Drain Current-Continuous 230 A IDM Drain Current-Single Pulsed 500 A PD Total Dissipation @TC=25℃ 650 W Tj Operating Junction Temperature -55~
