K4N25H - Photocoupler(These Photocouplers cosist of a Gallium Arsenide Infrared Emitting)
Photocoupler K4N25G K4N25H These Photocouplers cosist of a Gallium Arsenide Infrared Emitting Diode and a Silicon NPN Phototransistor in a 6-pin package.
7.62 6 5 4 0.25 6.4 DIMENSION (Unit : mm) 0.51Min.
3.8 TTL Compatible Output Collector-Emitter Voltage : Min.50V Current Transfer Ratio : Typ.100% (at IF=5mA, VCE=5V) Electrical Isolation Voltage : AC5000Vrms UL Recognized File No.
E107486 K4N25G - No Base Connection, K
K4N25H Features
* 0.25 1 2 3 0 -15 8.9 0.25 Orientation Mark 0.25 K4N25G PIN NO. AND INIERNAL CONNECION DIAGRAM 4 5 6 1 2.7Min. 0.5 2.54 0.25 1.2 2 5 3 4 APPLICATIONS
* Interface between two circuits of different potential
* Vending Machine, Copiers
* Measuring Instrument
