PCFFS3065AF, SiC Schottky Diode

Silicon Carbide (SiC) Schottky Diode * EliteSiC, 30 A, 650 V, D1, Die PCFFS3065AF DIE DATA SHEET www.onsemi.com Anode .
Silicon Carbide (SiC) Schottky Diodes use a completely new technology that provides superior switching performance and higher reliability compared to.

datasheet Preview Page 1 from Datasheet4u.com

PCFFS3065AF-ONSemiconductor.pdf

PCFFS3065AF Datasheet Preview — Preview of PCFFS3065AF PDF

Datasheet Details

Part number:

PCFFS3065AF

Manufacturer:

ON Semiconductor ↗

File Size:

138.35 KB

Description:

SiC Schottky Diode

Features

* Max Junction Temperature 175°C
* Avalanche Rated 180 mJ
* High Surge Current Capacity
* Positive Temperature Coefficient
* Ease of Paralleling

Applications

* General Purpose
* SMPS, Solar Inverter, UPS
* Power Switching Circuits For Additional Product Information and Electrical Characteristics on Package Refer to FFSP3065A product datasheet. Die Information
* Wafer Diameter: 6 inch
* Die Size: 2,700 × 2,700 mm (
