NP100N055PUK Datasheet, Transistor, Renesas

NP100N055PUK Features

• Transistor
• Super low on-state resistance RDS(on) = 3.25 m MAX. (VGS = 10 V, ID = 50 A)
• Low Ciss: Ciss = 4900 pF TYP. (VDS = 25 V)
• Designed for automotive application

PDF File Details

Part number:

NP100N055PUK

Manufacturer:

Renesas ↗

File Size:

103.84kb

Download:

📄 Datasheet

Description:

Mos field effect transistor. The NP100N055PUK is N-channel MOS Field Effect Transistor designed for high current switching applications. Features

Super

NP100N055PUK Application

• Applications Features
• Super low on-state resistance RDS(on) = 3.25 m MAX. (VGS = 10 V, ID = 50 A)
• Low Ciss: Ciss = 4900 pF TYP
