NP60N055MUK Datasheet, Transistor, Renesas

NP60N055MUK Features

• Transistor
• Super low on-state resistance RDS(on) = 6.0 m MAX. (VGS = 10 V, ID = 30 A)
• Low Ciss: Ciss = 2500 pF TYP. (VDS = 25 V)
• Designed for automotive application

PDF File Details

Part number:

NP60N055MUK

Manufacturer:

Renesas ↗

File Size:

106.63kb

Download:

📄 Datasheet

Description:

Mos field effect transistor. These products are N-channel MOS Field Effect Transistors designed for high current switching applications. Features

Super

NP60N055MUK Application

• Applications Features
• Super low on-state resistance RDS(on) = 6.0 m MAX. (VGS = 10 V, ID = 30 A)
• Low Ciss: Ciss = 2500 pF TYP.
