SGM61022 Datasheet, Converters, SG Micro

SGM61022 Features

• Converters
• Input Voltage Range: 2.3V to 5.5V
• Output Current: SGM61012: 1.2A SGM61022: 2A
• 8.5μA (TYP) Ultra-Low Quiescent Current in DSM
• AHP-COT Architecture

PDF File Details

Part number:

SGM61022

Manufacturer:

SG Micro

File Size:

1.30MB

Download:

📄 Datasheet

Description:

2a high-efficiency buck converters. The SGM61012 and SGM61022 are efficient high-frequency synchronous Buck converters with an input voltage range of 2.3V to 5.5V and a

SGM61022 Application

• Applications General Purpose Point-of-Load Power Supplies Battery-Powered Applications TYPICAL APPLICATION VIN VIN PG 10kΩ C1 C2 1μH EN SGM
