STGB10NC60KD Datasheet, Igbt, ST Microelectronics

STGB10NC60KD Features

• Igbt
• Lower on voltage drop (VCE(sat))
• Lower CRES / CIES ratio (no cross-conduction susceptibility)
• Very soft ultra fast recovery antiparallel diode
• Sh

PDF File Details

Part number:

STGB10NC60KD

Manufacturer:

STMicroelectronics ↗

File Size:

522.62kb

Download:

📄 Datasheet

Description:

600v short-circuit rugged igbt. This IGBT utilizes the advanced PowerMESH™ process resulting in an excellent trade-off between switching performance and low on-state

STGB10NC60KD Application

• Applications
• High frequency motor controls
• SMPS and PFC in both hard switch and resonant topologies
• Motor drives TAB
