SVS7N70FD2 Datasheet, Transistor, Silan Microelectronics

📥 Download PDF (393.31 KB)

PDF File Details

Silan Microelectronics manufacturer logo

Part number:

SVS7N70FD2

Manufacturer:

Silan Microelectronics

File Size:

393.31 KB

Download:

📄 Datasheet

Description:

700v super junction mos power transistor. SVS7N70F(D)(MJ)(S)D2 is an N-channel enhancement mode high voltage power MOSFETs produced using Silan’s super junction MOS technology

✔ SVS7N70FD2 Features

2 1 3 1.Gate 2.Drain 3.Source 1 3 TO-252-2L 1 3 TO-263-2L
7A, 700V, RDS(on)(typ.)=0.52@VGS=10V
New revolutionary high voltage technology
Ultra low gate charge
