SKY73022-11 - High Gain and Linearity Diversity Downconversion Mixer

Datasheet Summary

Description

2G/3G base station transceivers: The SKY73022-11 is a fully integrated diversity mixer that GSM/EDGE, CDMA, UMTS/WCDMA, iDEN includes Local Oscillator (LO) drivers, an LO switch, high linearity Land mobile radio ISM band transceivers High perfor

Features

Operating frequency range: 700 to 1000 MHz U.
IF frequency range: 40 to 300 MHz.
Conversion gain: 9.4 dB.
Input IP3: +25.3 dBm IN.
Output IP3: +34.7 dBm.
Noise figure: 9.0 dB.
Integrated LO drivers T.
Integrated low loss RF baluns.
High linearity IF amplifiers N.
On-chip SPDT LO switch (greater than 53 dB LO-to-LO isolation).
Small, MCM (36-pin, 6 x 6 mm) Pb-free package (MSL3, 260 °C per JEDEC J-.

Datasheet Details

Part number	SKY73022-11
Manufacturer	Skyworks
File Size	968.75 KB
Description	High Gain and Linearity Diversity Downconversion Mixer
Datasheet	SKY73022-11 Datasheet
Additional preview pages of the SKY73022-11 datasheet.

📁 Similar Datasheet

SKY73020 - High Gain and Linearity Diversity Downconversion Mixer (Skyworks Solutions)

SKY73021 - High Gain and Linearity Diversity Downconversion Mixer (Skyworks Solutions)

SKY73023 - High Gain and Linearity Diversity Downconversion Mixer (Skyworks Solutions)

SKY73001 - Direct Conversion Mixer (Skyworks Solutions)

SKY73009 - Direct Quadrature Demodulator (Skyworks Solutions)

SKY73010 - Direct Quadrature Modulator (Skyworks Solutions)

SKY73012 - Direct Quadrature Demodulator (Skyworks Solutions)

SKY73032 - High Gain and Linearity Diversity Downconversion Mixer (Skyworks Solutions)

SKY73033 - High Gain and Linearity Diversity Downconversion Mixer (Skyworks Solutions)

SKY73035 - High Gain and Linearity Diversity Downconversion Mixer (Skyworks Solutions)

Full PDF Text Transcription

Click to expand full text

DATA SHEET SKY73022-11: 700 – 1000 MHz High Gain and Linearity Diversity Downconversion Mixer Applications Description • 2G/3G base station transceivers: The SKY73022-11 is a fully integrated diversity mixer that − GSM/EDGE, CDMA, UMTS/WCDMA, iDEN includes Local Oscillator (LO) drivers, an LO switch, high linearity • Land mobile radio • ISM band transceivers • High performance radio links D • RF identification E Features • Operating frequency range: 700 to 1000 MHz U • IF frequency range: 40 to 300 MHz • Conversion gain: 9.4 dB • Input IP3: +25.3 dBm IN • Output IP3: +34.7 dBm • Noise figure: 9.
