TC74HC109AFN - DUAL J-K FLIP-FLOP

Product Overview

Toshiba

📥 Download Datasheet

TC74HC109AFN DUAL J-K FLIP-FLOP by Toshiba - Datasheet Preview — Datasheet preview – TC74HC109AFN

Datasheet Details

Part number	TC74HC109AFN
Manufacturer	Toshiba
File Size	229.40 KB
Description	DUAL J-K FLIP-FLOP
Datasheet	TC74HC109AFN Datasheet
Note	This datasheet PDF includes multiple part numbers: TC74HC109AFN, TC74HC109. Please refer to the document for exact specifications by model.
Additional preview pages of the TC74HC109AFN datasheet.

Product details

Features

High speed: fmax = 63 MHz (typ. ) at VCC = 5 V.
Low power dissipation: ICC = 2 μA (max) at Ta = 25°C.
High noise immunity: VNIH = VNIL = 28% VCC (min).
Output drive capability: 10 LSTTL loads.
Symmetrical output impedance: |IOH| = IOL = 4 mA (min).
Balanced p.
