QM2402K N-Ch 20V Fast Switching MOSFETs

The QM2402K is the highest performance trench N-ch MOSFETs with extreme high cell density , which provide excellent RDSON and gate charge for most of the small power switching and load switch applications. The QM2402K meet the RoHS and Green Product requirement with full function reliability approve.

QM2402K Features

* z Advanced high cell density Trench technology z Super Low Gate Charge z Excellent Cdv/dt effect decline z Green Device Available Product Summery BVDSS 20V RDSON 28mΩ ID 4.8A Applications z High Frequency Point-of-Load Synchronous Small power switching for MB/NB/UMPC/VGA z Networking DC-DC Powe
