ZL30131 - Network Interface Synchronizer

Zarlink Semiconductor

Datasheet Details

Part number	ZL30131
Manufacturer	Zarlink Semiconductor
File Size	1.06 MB
Description	Network Interface Synchronizer
Datasheet	ZL30131-ZarlinkSemiconductor.pdf

Synchronizes to standard telecom or Ethernet backplane clocks and provides jitter filtered output clocks for SONET/SDH, PDH and Ethernet network interface cards.
Supports the requirements of ITU-T G.8262 for synchronous Ethernet Equipment slave Clocks (EEC option 1 and 2).
Two independent DPLLs provides timing for the transmit path (backplane to line rate) and the receive path (recovered line rate to backplane).
Synchronizes to telecom reference clocks (2 kHz.
