MX2301 - P-Channel Power MOSFET

MX2301 Description

P-Channel Enhancement Mode Power MOSFET MX2301 .
The MX2301 uses advanced trench technology to provide excellent RDS(ON) and low gate charge.

MX2301 Features

* VDS=-20V, ID=-3A RDS(ON)(Typ. )=110mΩ @ VGS=-2.5V RDS(ON)(Typ. )=85mΩ @ VGS=-4.5V
* High Power and current handing capability
* Lead free product is acquired

📥 Download Datasheet

Preview of MX2301 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
MX2301
Manufacturer
ChipSourceTek
File Size
670.39 KB
Datasheet
MX2301-ChipSourceTek.pdf
Description
P-Channel Power MOSFET
