MX2305 Datasheet, Mosfet, ChipSourceTek

MX2305 Features

• Mosfet VDS =-20V，ID =-4A RDS(ON)(Typ.) < 38mΩ @ VGS=-4.5V Schematic diagram RDS(ON) (Typ.)< 54mΩ @ VGS=-2.5V ESD Rating: 2500V HBM High Power and current handing capability Lead free prod

PDF File Details

Part number:

MX2305

Manufacturer:

ChipSourceTek

File Size:

0.99MB

Download:

📄 Datasheet

Description:

P-channel power mosfet. The MX2305 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gatevoltages as low as1.8

MX2305 Application

• Applications .It is ESD protected. MX2305 General Features VDS =-20V，ID =-4A RDS(ON)(Typ.) < 38mΩ @ VGS=-4.5V Schematic diagram RDS(ON) (Typ.)
