CY7C1643KV18 - 144-Mbit QDR II+ SRAM Four-Word Burst Architecture

Name: CY7C1643KV18
SKU: CY7C1643KV18-1101469

Cypress Semiconductor

The CY7C1643KV18 by Cypress Semiconductor is a 144-Mbit QDR II+ SRAM Four-Word Burst Architecture. Below is the official datasheet preview.

📥 Download Datasheet

CY7C1643KV18 144-Mbit QDR II+ SRAM Four-Word Burst Architecture by Cypress Semiconductor - Datasheet Preview — Official preview page of the **CY7C1643KV18** 144-Mbit QDR II+ SRAM Four-Word Burst Architecture datasheet (Cypress Semiconductor).

Datasheet Details

Part number	CY7C1643KV18
Manufacturer	Cypress Semiconductor
File Size	1.20 MB
Description	144-Mbit QDR II+ SRAM Four-Word Burst Architecture
Datasheet	CY7C1643KV18-CypressSemiconductor.pdf
Additional preview pages of the CY7C1643KV18 datasheet.

CY7C1643KV18 Product details

Features

Separate independent read and write data ports.
Supports concurrent transactions.
450-MHz clock for high bandwidth.
Four-word burst for reducing address bus frequency.
Double data rate (DDR) interfaces on both read and write ports (data transferred at 900 MHz) at 450 MHz.
Available in 2.0-clock cycle latency.
Two input clocks (K and K) for precise DDR timing.
SRAM uses rising edges only.
Echo clocks (CQ and CQ) simplify data capture in high-speed sys.
