FDMS2572 Datasheet, Mosfet, Fairchild Semiconductor

FDMS2572 Features

• Mosfet General Description
• Max rDS(on) = 47mΩ at VGS = 10V, ID = 4.5A
• Max rDS(on) = 53mΩ at VGS = 6V, ID = 4.5A
• Low Miller Charge
• Optimized efficiency

PDF File Details

Part number:

FDMS2572

Manufacturer:

Fairchild Semiconductor

File Size:

484.17kb

Download:

📄 Datasheet

Description:

N-channel ultrafet trench mosfet.

Max rDS(on) = 47mΩ at VGS = 10V, ID = 4.5A

Max rDS(on) = 53mΩ at VGS = 6V, ID = 4.5A

Low Miller Charge

FDMS2572 Application

• Applications Optimized for rDS(on), low ESR, low total and Miller gate charge, these devices are ideal for high frequency DC to DC converters. Appl
