IRF654 - 250V N-Channel MOSFET

IRF654 Description

IRF654B/IRFS654B November 2001 IRF654B/IRFS654B 250V N-Channel MOSFET General .
These N-Channel enhancement mode power field effect transistors are produced using Fairchild’s proprietary, planar, DMOS technology.

IRF654 Features

* 21A, 250V, RDS(on) = 0.14Ω @VGS = 10 V Low gate charge ( typical 95 nC) Low Crss ( typical 60 pF) Fast switching 100% avalanche tested Improved dv/dt capability D G G DS TO-220 IRF Series GD S TO-220F IRFS Series S Absolute Maximum R

📥 Download Datasheet

Preview of IRF654 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
IRF654
Manufacturer
Fairchild Semiconductor
File Size
867.92 KB
Datasheet
IRF654_FairchildSemiconductor.pdf
Description
250V N-Channel MOSFET
