STW26NM50 N-Channel MOSFET

STW26NM50 Description

isc N-Channel MOSFET Transistor *.

STW26NM50 Features

* With TO-247 packaging
* With low gate drive requirements
* Easy to drive
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

STW26NM50 Applications

* Switching applications
* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage 500 VGSS ID IDM Gate-Source Voltage Drain Current-Continuous @Tc=25℃ Tc=100℃ Drain Current-Single Pulsed ±30 30 18.9 120 PD Total Dissipation 313 Tj Operating Junction Te

📥 Download Datasheet

Preview of STW26NM50 PDF
datasheet Preview Page 2

Datasheet Details

Part number
STW26NM50
Manufacturer
INCHANGE
File Size
257.05 KB
Datasheet
STW26NM50-INCHANGE.pdf
Description
N-Channel MOSFET
