RF1S30P06SM Datasheet, Mosfet, Intersil Corporation

RF1S30P06SM Features

• Mosfet
• 30A, 60V
• rDS(ON) = 0.065Ω
• Temperature Compensating PSPICE® Model
• Peak Current vs Pulse Width Curve
• UIS Rating Curve
• 175oC Ope

PDF File Details

Part number:

RF1S30P06SM

Manufacturer:

Intersil Corporation

File Size:

71.16kb

Download:

📄 Datasheet

Description:

P-channel power mosfet.

RF1S30P06SM Application

• Applications such as switching regulators, switching converters, motor drivers, and relay drivers. These transistors can be operated directly from i
