MGFC39V5964A Datasheet, Fet, Mitsubishi

Image	Manufacturer	Part Number	B2B mpn	Description	Distributor	In Stock	Quantity	Price	Buy Now
	Mitsubishi Electric	MGFC39V5964A	MGFC39V5964A-61	C BAND, GAAS, N-CHANNEL, RF POWER, JFET	Quest Components	101	57 units	$34.5	🛒 Buy Now

📥 Download PDF (86.29 KB)

PDF File Details

Mitsubishi manufacturer logo

Part number:

MGFC39V5964A

Manufacturer:

Mitsubishi

File Size:

86.29 KB

Download:

📄 Datasheet

Description:

C band internally matched power gaas fet. The MGFC39V5964A is an internally impedance-matched GaAs power FET especially designed for use in 5.9 * 6.4 GHz band amplifiers. The

✔ MGFC39V5964A Features

Class A operation Internally matched to 50(ohm) system
High output power P1dB=8W (TYP.) @f=5.9
6.4GHz
High power gain GLP=10.5dB (TYP.) @f=5.9
6.4GHz
High power
