STF16NK60Z Datasheet, Mosfet, STMicroelectronics

STF16NK60Z Features

• Mosfet Type STF16NK60Z STP16NK60Z STW16NK60Z VDSS 600 V 600 V 600 V RDS(on) max ID Pw < 0.42 Ω 14 A(1) 40 W < 0.42 Ω 14 A 190 W < 0.42 Ω 14 A 190 W 1. Limited by package.
• 1

PDF File Details

Part number:

STF16NK60Z

Manufacturer:

STMicroelectronics ↗

File Size:

723.49kb

Download:

📄 Datasheet

Description:

N-channel power mosfet. The new SuperMESH™ series of Power MOSFETS is the result of further design improvements on ST's well-established stripbased PowerMESH

STF16NK60Z Application

• Applications Description The new SuperMESH™ series of Power MOSFETS is the result of further design improvements on ST's well-established stripbase
