2SJ619 - Silicon P-Channel MOSFET

2SJ619 Description

2SJ619 TOSHIBA Field Effect Transistor Silicon P Channel MOS Type (L2-π-MOSV) 2SJ619 Switching Regulator and DC-DC Converter Applications Motor Drive.

2SJ619 Applications

* Motor Drive Applications Unit: mm
* 4-V gate drive
* Low drain-source ON resistance: RDS (ON) = 0.15 Ω (typ. )
* High forward transfer admittance: ⎪Yfs⎪ = 7.7 S (typ. )
* Low leakage current: IDSS =
* 100 µA (max) (VDS =
* 100 V)
* Enhancement mo

📥 Download Datasheet

Preview of 2SJ619 PDF
datasheet Preview Page 2 datasheet Preview Page 3
