WNMD2154 Datasheet, Mosfet, Will Semiconductor

WNMD2154 Features

• Mosfet z Trench Technology z Supper high density cell design z Excellent ON resistance z Extremely Low Threshold Voltage z Small package SOT-563 WNMD2154 Http//:www.willsemi.com SOT-563 D1 G2

PDF File Details

Part number:

WNMD2154

Manufacturer:

Will Semiconductor

File Size:

283.17kb

Download:

📄 Datasheet

Description:

Dual n-channel mosfet. The WNMD2154 is N-Channel enhancement MOS Field Effect Transistor. Uses advanced trench technology and design to provide excellent R

WNMD2154 Application

• Applications z DC-DC converter circuit z Load Switch z Level Shift Order information Device Package Shipping WNMD2154-6/TR SOT-563 3000/Reel&Ta
