CY7C1265V18 1.8V Synchronous Pipelined SRAM

CY7C1265V18 Features

* Separate independent read and write data ports

* Supports concurrent transactions

* 300 MHz to 400 MHz clock for high bandwidth

* 4-Word Burst for reducing address bus frequency

* Double Data Rate (DDR) interfaces on both read and write ports (data transferred at 800 MHz) at 40

Datasheet Details

CY7C1265V18, CY7C1261V18

Cypress Semiconductor

404.82 KB

1.8v synchronous pipelined sram.

This datasheet PDF includes multiple part numbers: CY7C1265V18, CY7C1261V18.
Please refer to the document for exact specifications by model.
