CY7C1563XV18 72-Mbit QDR II+ Xtreme SRAM Four-Word Burst Architecture

CY7C1563XV18 Features

* Separate Independent Read and Write Data Ports

* Supports concurrent transactions

* 633 MHz Clock for High Bandwidth

* Four-word Burst for Reducing Address Bus Frequency

* Double Data Rate (DDR) Interfaces on both Read and Write Ports (data transferred at 1266 MHz) at 633 MHz
